Concentro S503 3-Way 7" Bookshelf Speaker (Each)
Meet Concentro S 503
Defining the Future of Sound... in a Smaller Package.
Be in no doubt, the S 503 is a true Concentro in every respect. Design features and technical details that drove the success of the S 507 and S 509 are now combined in compact dimensions.
The trapezoid basic shape, convex shaped baffle, and gently angled cabinet combine in a strikingly organic way to create a strong visual statement. The extensive list of patented features and the revised woofer magnet system guarantee superlative sound. The effortless performance can be adjusted to suit the room acoustics. Close your eyes and you’ll instantly forget you’re listening to a compact speaker ... all you hear is music.
The Concentro S 503 is available in black and white high- gloss finishes and in high-gloss walnut veneer. The LS 100 stand specially developed for the Concentro S 503 is an available option.
SPECIFICATIONS
| Height | 400 mm |
|---|---|
| Width | 225 mm |
| Depth | 372 mm |
| Weight | 13.4 kg |
| Type | 3-way, bass reflex |
| Woofer | 1x180 mm, AS-XR cone |
| Midrange | 1 x 50 | 130 mm 0, AS-XR AL cone |
| Tweeter | JET 5c |
| Crossover frequency | 400 | 2600 Hz |
| Nominal/peak power handling | 120 W1200 W |
| Minimum impedance | 4,8 Ω bei 120 Hz |
| Peak power handling | 400 W |
| Sensitivity | 87 dB / 2,83 V/m |
| Suitable for amplifiers from ... to Nominal impedance | 4-8 Ω |
| Nomial impedance | 60 - 500 W/channel |
| Recommended amplifier power | 4 Ω |
| Finishes | High-Gloss - Black Lacquer, White Lacquer, Walnut Veneer |
| Accessories | Bi-Wiring-jumper set, |
| Accessories | 3 DCR (Directivity Control Ring) |
